OCR Integration with Pega 7
Hi there,
Just looking for advise/suggestion on OCR integration. Use case is: We want to be able to scan an image (Drivers license) and pre-populate the application form from the scanned document. Looking for software which was used, whether it is possible or not etc.
Thanks,
Jai
-
Like (0)
-
Share this page Facebook Twitter LinkedIn Email Copying... Copied!
Accepted Solution
Updated: 7 Dec 2015 11:41 EST
![](/themes/custom/pegacc_theme/images/user-icon.png)
![](/themes/custom/pegacc_theme/images/user-icon.png)
I've successfully built out a proof-of-concept level integration with Tesseract via the Tess4J library. It's well beyond out-of-the-box Pega functionality, but Tesseract is one of the most efficient and accurate OCR implementations available... and it's open source.
Since Tesseract is a native library (compiled code / .dll or .so binary) it requires installation on the server machine, which will vary based on OS and processor architecture. The final result is a system that looks something like this, where parenthesis represent "wrapping" or calling:
Data Transform(Function Rule(Java Class(JNA(Tesseract Library(image file)))))
Tess4J handles the Java Class and JNA portions of the architecture, which would be the most challenging pieces for a Pega Developer. Prior to calling the function, the image file needs to be written to disk in a location accessible to the Tesseract library. For attachments, this means they need to be extracted from the database and written as a java.io.File object. Once OCR has been performed, the file can be deleted.
I've successfully built out a proof-of-concept level integration with Tesseract via the Tess4J library. It's well beyond out-of-the-box Pega functionality, but Tesseract is one of the most efficient and accurate OCR implementations available... and it's open source.
Since Tesseract is a native library (compiled code / .dll or .so binary) it requires installation on the server machine, which will vary based on OS and processor architecture. The final result is a system that looks something like this, where parenthesis represent "wrapping" or calling:
Data Transform(Function Rule(Java Class(JNA(Tesseract Library(image file)))))
Tess4J handles the Java Class and JNA portions of the architecture, which would be the most challenging pieces for a Pega Developer. Prior to calling the function, the image file needs to be written to disk in a location accessible to the Tesseract library. For attachments, this means they need to be extracted from the database and written as a java.io.File object. Once OCR has been performed, the file can be deleted.
If only a portion of the file needs to be read, Tesseract supports passing in the coordinates of a rectangle representing the area of the image to be read. Alternatively, the image could be cropped prior to running OCR on it.
![](https://accounts.pega.com/sites/default/files/pega-user-image/39/REG-38808.png?source=PUMINIT)
![](https://accounts.pega.com/sites/default/files/pega-user-image/39/REG-38808.png?source=PUMINIT)
Pegasystems Inc.
IN
Hello,
I am afraid, unfortunately, we don't have any tool as yet that supports the integration with OCR/ICR software.
If you want to do the scanning from the application itself, you can refer this KB Article : http://pdn.pega.com/node/11722
Then you can follow the steps mentioned here to read the scanned item : https://community.pega.com/integration/pega-content-management-capture-store-and-view-content
Accepted Solution
Updated: 7 Dec 2015 11:41 EST
![](/themes/custom/pegacc_theme/images/user-icon.png)
![](/themes/custom/pegacc_theme/images/user-icon.png)
I've successfully built out a proof-of-concept level integration with Tesseract via the Tess4J library. It's well beyond out-of-the-box Pega functionality, but Tesseract is one of the most efficient and accurate OCR implementations available... and it's open source.
Since Tesseract is a native library (compiled code / .dll or .so binary) it requires installation on the server machine, which will vary based on OS and processor architecture. The final result is a system that looks something like this, where parenthesis represent "wrapping" or calling:
Data Transform(Function Rule(Java Class(JNA(Tesseract Library(image file)))))
Tess4J handles the Java Class and JNA portions of the architecture, which would be the most challenging pieces for a Pega Developer. Prior to calling the function, the image file needs to be written to disk in a location accessible to the Tesseract library. For attachments, this means they need to be extracted from the database and written as a java.io.File object. Once OCR has been performed, the file can be deleted.
I've successfully built out a proof-of-concept level integration with Tesseract via the Tess4J library. It's well beyond out-of-the-box Pega functionality, but Tesseract is one of the most efficient and accurate OCR implementations available... and it's open source.
Since Tesseract is a native library (compiled code / .dll or .so binary) it requires installation on the server machine, which will vary based on OS and processor architecture. The final result is a system that looks something like this, where parenthesis represent "wrapping" or calling:
Data Transform(Function Rule(Java Class(JNA(Tesseract Library(image file)))))
Tess4J handles the Java Class and JNA portions of the architecture, which would be the most challenging pieces for a Pega Developer. Prior to calling the function, the image file needs to be written to disk in a location accessible to the Tesseract library. For attachments, this means they need to be extracted from the database and written as a java.io.File object. Once OCR has been performed, the file can be deleted.
If only a portion of the file needs to be read, Tesseract supports passing in the coordinates of a rectangle representing the area of the image to be read. Alternatively, the image could be cropped prior to running OCR on it.
![](https://accounts.pega.com/sites/default/files/styles/user_image/public/1690953000/5be3b54b-b897-46db-9bd8-49e9c911395d.jpg?itok=5opjXxyQ)
![](https://accounts.pega.com/sites/default/files/styles/user_image/public/1690953000/5be3b54b-b897-46db-9bd8-49e9c911395d.jpg?itok=5opjXxyQ)
Pegasystems Inc.
DE
Hi Zane,
I have a customer with the same requirement.
Do you have any screenshots / videos / documentation / RAP etc. of your PoC you can share?
Especially some screenshots would be really helpful.
Best regards,
Florian
Updated: 6 Apr 2016 13:45 EDT
![](https://accounts.pega.com/sites/default/files/styles/user_image/public/1690953000/5be3b54b-b897-46db-9bd8-49e9c911395d.jpg?itok=5opjXxyQ)
![](https://accounts.pega.com/sites/default/files/styles/user_image/public/1690953000/5be3b54b-b897-46db-9bd8-49e9c911395d.jpg?itok=5opjXxyQ)
Pegasystems Inc.
DE
Update:
Unfortunately I was not able to find much more information than what is discussed on this thread, but there are different options available:
- Backend-based integration with OCR system (e.g. we put an image file / pdf somewhere or hand it over via web service to the OCR system and receive a structured system readable response back with the results)
- Fronted-based integration with OCR system (we integrate a web-based / plugin based UI into Pega and communicate through JavaScript + maybe backend based integration in addition to that)
- Native OCR implementation with 3rd party library in Pega (i.e. based on Tesseract / Tess4J like discussed in this thread)
- Application switch (worst option in terms of user experience, but easiest from implementation point of view and in order to save existing investments --> i.e. the user switches to the OCR application, uploads the file manually and then either receives an XML / CSV file as a result which he manually uploads in Pega or puts it into a folder with the Case ID in the filename and Pega picks it up)
Here are the options we discussed:
Update:
Unfortunately I was not able to find much more information than what is discussed on this thread, but there are different options available:
- Backend-based integration with OCR system (e.g. we put an image file / pdf somewhere or hand it over via web service to the OCR system and receive a structured system readable response back with the results)
- Fronted-based integration with OCR system (we integrate a web-based / plugin based UI into Pega and communicate through JavaScript + maybe backend based integration in addition to that)
- Native OCR implementation with 3rd party library in Pega (i.e. based on Tesseract / Tess4J like discussed in this thread)
- Application switch (worst option in terms of user experience, but easiest from implementation point of view and in order to save existing investments --> i.e. the user switches to the OCR application, uploads the file manually and then either receives an XML / CSV file as a result which he manually uploads in Pega or puts it into a folder with the Case ID in the filename and Pega picks it up)
Here are the options we discussed:
The final decision will be made during the inception of the project and I will post an update then - and later based on the implementation.
For our vision demo, we simulated the OCR part, but included how the UI would look like with options 1-3.
In this case a PDF order would have been OCR'd / parsed already and shown to the Order Manager for verification & validation (we are showing the results on the left hand side and the original PDF document on the right). This would be the case with option 1, 2 and 3, but the actual capabilities would differ (e.g. with option 2 and 3 we would have the possibility to interact on the UI, e.g. select something visually in the PDF and then automatically generate a new order item on the left - with option 1 (backend integration only) this would be a manual change when it comes to the validation step).
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
Financial Services
AU
Apologies for not replying to your message Zane Beckman . We started looking at Tessaract and Microblink as well. We are also exploring some options with Kofax & Jumio. Thanks for your suggestion.
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
Cognizant Technology Solutions
AU
Hi,
Does PEGA support OOTB capability to integrate with Kofax, according to https://www.pega.com/about/news/media-coverage/kofax-and-pegasystems-partner it does.
I'm not able to see any references on PDN/ mesh for Kofax. Could you please provide your thoughts on this integration capability? Appreciate your help.
Thanks,
Sadaan
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
AGCS
DE
Check this link... Pega SFA has OCR integrated into it now. This is a live demo.
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
![](/profiles/pega_profile/modules/pega_user_image/assets/user-icon.png)
BlueRose Technologies
GB
Is there any step by step guide, which explains the feature in Pega SA and how to use it?
